At a satellite event to Intel’s Developer Conference last week, AMD held an evening soiree with invited analysts and press to talk about their new upcoming Zen microarchitecture. This was intended to be a preview of tomorrow’s Hot Chips presentation, and we’ve already covered the juicier parts of the presentation in terms of microarchitecture announcements as well as diving deep into the Server-based Naples implementation and what the motherboards told us from memory and IO support.

You can read both here:

AMD Zen Microarchitecture: Dual Schedulers, Micro-op Cache and Memory Hierarchy Revealed
AMD Server CPUs and Motherboard Analysis

There was one other element to the presentation that requires further discussion and analysis, if only to clean up some of the misinformation already present online and to label what was shown with a long list of potential caveats which most people seem to have passed by almost entirely. As part of the show, AMD compared the performance of their Zen engineering sample to an Intel Broadwell-E processor.

In this test, they told the audience that each system was running eight cores, sixteen threads, and will all cores set to 3 GHz (implying no turbo). Memory arrangements were not disclosed, nor storage: we were told to assume comparable setups.

We were too busy trying to decipher what was on screen (and take note of the results) to actually photograph the benchmark as it happened (there are videos online), but the benchmark they showed was Blender, an open source rendering engine, with a custom multithreaded workload. The test was to render a mockup of a Zen based desktop CPU, with an effective workload of 50 seconds for these chips. I’ve seen numerous reports about this result saying the difference was 1 or 2 seconds, but with rarely a mention of the benchmark length, which is as important. The overall results were

All things being equal (we’ll get to that in a second), this would suggest that an 8-core AMD has a ~2% advantage over Broadwell-E at the same clock speeds. Despite this result, there are a lot of unverifiable parts to the claim which makes analysis of such a result difficult. I want to go through each of them one by one to ensure everyone understands what was presented.

I’ll preface this analysis with two things though: one is that AMD was very careful in what they said at the event, and only said as much as they needed to. Thus is why the string of caveats for this benchmark test is fairly long. But also, AMD has to set expectations here: if they choose an environment and test that represents the peak, or relies on something special, users will feel burned again after Bulldozer. AMD has to temper those expectations but still represent a methodology that is effective to them. By leaving so many cards on the table, this can both be a help or a hindrance.

But given the measured and calm, professional nature of the event, as opposed to the wild and wacky AMD events of the past, it was clear (either by design or chance) that the words used said only as much as they needed to. Along with the microarchitecture discussions, it was designed to provide a good stepping stone on to the Hot Chips presentation a few days later.

So, caveats. Or disclaimers not readily provided. Let’s start at the top.

1) The Results Are Not Externally Verifiable At This Time, As Expected

We were told the setups of the systems being used, but were unable to confirm the results manually. This is typically the case with a high level, early look at performance and other companies do this all the time.

This being said, it would look bad on reports if it to turns out or someone finds a chasm between pre-launch and launch data, so the aspect of reporting this data without understanding this caveat is fundamental. The basis of publishing scientific papers is repeatability and verification – while this wasn’t a scientific presentation, it is important to keep it in the back of your mind when you hear any benchmark numbers (AnandTech included – our numbers are designed to be verifiable and we want to have a history of honesty with our readers, especially when it comes to custom software/workloads we cannot disclose).

2) No Memory or TDP Numbers Were Provided

We were able to determine that the AMD-based systems were running 2×8 GB of DDR4-2400, although we did not get a look at Intel’s memory arrangement. Similarly, due to the ES nature of the CPU, TDP numbers were also not shared however we did see all the AMD systems use either the AMD Wraith cooler (which is rated at 125W) or the new near silent cooler (95W). That tends to peg the system at a peak power consumption and some of AMD’s current competitive parts actually use a cooler designed for the bracket above in TDP (e.g. A10-7860K at 65W uses the 95W cooler, A10-7890K at 95W uses the 125W cooler).

3) Blender Is an Open Source Platform

One of the issues of using open source is that the code is editable by everyone and anyone. Any user can adjust the code to optimize for their system and run a test to get a result. That being the case, it can be difficult to accurately determine the code base for this test, and is relatively impossible to determine the code base of Blender that was compiled for this test.

Even in the base code, there could be CPU vendor specific optimizations in either the code or compiler that influences how the code manipulates the cache hierarchy with the workload and adjusts appropriately. It also doesn’t help that Blender has elements in the code called ‘AMD’, which relates to a series of internal rendering features not related to the company. Going down the optimization for specific CPU microarchitectures leads on to another more philosophical issue…

4) Did It Actually Measure IPC? (The Philosophical Debate)

In the purest sense, measuring the number of instructions per clock that a set of instructions can perform can determine the efficiency of a design. However, the majority of highly optimized code bases do not have general-purpose code – if it detects a particular microarchitecture it can manipulate threads and loops to take advantage of the code design. How should IPC be measured is the main question: using identical code bases makes it easier to understand but are often non-real-world compiler targets, or highly optimized code to show the best of what the processor can do (which means that IPC performance is limited to that benchmark)? With the results we saw, if the difference of about a second in just under fifty seconds translates into a 2% difference, is it accurate to say that this is a 2% IPC increase, or does it rely on optimized/non-optimized code? Optimizing code, or profiling compilers for specific code targets, is nothing new. In the holistic view, most analysts use SPEC benchmarks for this, as they are well-known code structures, even though most benchmarks are compiler targets – while SPEC is not particularly relevant for the real world workloads, it does give an indication about performance for unknown architectures/microarchitectures.

5) The Workload Is Custom

One of the benefits of software like SPEC, or canned benchmarks like Cinebench, is that anyone (with a license) can pick up the workload and run with it. Those workloads are typically well known, and we can get performance numbers out that have known qualities in their interpretation. With a custom workload, that is not always the case. It comes down to experience – an unknown workload can have a lop-sided implementation of certain branches of code which is unknown when it comes to running the results. This is why rendering one scene in a film can take a vastly different time to another, yet the results for the ‘benchmark’ are significantly different depending on the architecture (one prefers lighting, another prefers tessellation etc.) Using known or standard workloads over long periods of time can offer insights into the results, whereas new workloads cannot, especially with so few results on offer.

6) It Is Only One Benchmark

There is a reason for AMD only showing this benchmark – it’s either a best case scenario, or they are pitching their expectations exactly where they want people to think. By using a custom workload on open source software, the result is very specific and cannot be extrapolated in any meaningful way. This is why a typical benchmark suite offers 10-20 tests with different workloads, and even enterprise standard workloads like SPEC come with over a dozen tests in play, to cater for single thread or multi-thread or large cache or memory or pixel pushing bottleneck that may occur. Single benchmarks on their own are very limited in scope as a result.

7) There’s Plenty about the Microarchitecture and Chip We Don’t Know Yet, e.g. Uncore

One of the more difficult elements on a processor is managing cross-core communication, as well as cross-core-cache snooping. This problem is overtly exponential, with the plausibility of more direct connections per core as the numbers go up. Intel has historically used a torus (ring) interconnect between cores to do this, with their large multi-core chips using a dual ring bus with communication points between the two. We suspect AMD is also using a ring bus in a similar methodology, but this has not been discussed at this time. There’s also the interconnect fabric between the cores and other parts of the chip, such as the Northbridge/Southbridge or the memory controllers. Depending on the test, the core-to-core communication and the interconnect can have different performance effects on the CPU.

8) Clock Speeds Are Not Final, Efficiency Not Known

Performance of a CPU is…
